Decorative Green RAL6005 Weld Wire Mesh Fencing
Material: | Electric Galvanized Wire | Color: | White, Green, Yellow |
---|---|---|---|
Wire Dia: | 5.0mm | Hole Size: | 200mm X 50mm |
Technique: | Professional Welding | Application: | Isolation Fence For Garden, Residential, Aireport |
Post Model: | Square Post ,Mushroom Shape, Quadrate Fence Post | Feature: | Nice Appearance, Strong Structure |
High Light: |
welded wire mesh fencing, garden wire mesh fencing |
Green RAL6005 Weld Wire Mesh Decorative Fencing Designs
Weld mesh fencing is the most common Wire mesh fencing designs. It is very hot products for a lot of western countries,such as UK,USA,Canada,Australia,Singapore etc. 3D wire mesh fence panel is a very attractive and cost effective solution. The panels feature ‘V’ shaped beams at the top, center and bottom edges, which not only enhance the appearance but also provide an integral support spanning between the posts.
Features:
Easy Installation, Cost effective, Nice looking
Different options on color according to the using environment
Strong anti rust and anti corrosion ability
Different options of install clips such as metal or plastic
Different options of post
Application:
Fence has many uses. It works well if you are looking for something to line and protect your property. Perhaps you are trying to create an enclosed space to keep your children or pets safe. Another great use is creating a barrier around your garden to keep animals from getting in or burrowing through. For small animal protection, you could also choose hexagonal wire netting, welded wire mesh, field wire fence, chicken wire netting.
Surface treatment after welded:
1>Powder spray coated (thickness 0.1mm)
2>PVC/PE dipped coating (thickness 0.8-1.2mm)
3>electro galvanized (zinc thickness : 20-60g/m2)
4>Hot dipped galvanized (zinc thickness : 280-500g/m2)
Choice Of Colors:
Every RAL colour desired can be delivered, for example the colours corresponding to your corporate design.
- Common colors
- Dark Green RAL6005
- Pure White RAL9010
- Stone Grey RAL7030
- Jet Black RAL9005
- Anthracite Grey RAL7016
- Other RAL colors are available
Specification
Wire Diameter | Mesh Size | Length | Height | Fold No. | Square Post Size | Common Colour |
3.0mm4.0mm
4.5mm 5.0mm 5.5mm 6.0mm |
50x200mm55x200mm
50x100mm 75x150mm |
2000mm2200mm
2500mm 3000mm |
1030mm | 2 | 50x50x1.5/2.0mm60x60x1.5/2.0mm
80x80x1.5/2.0mm |
Green RAL6005Black RAL9005
White RAL9010 Grey RAL7030 Red RAL3020 Yellow RAL1023 Blue RAL5017 |
1230mm | 2 | |||||
1530mm | 3 | |||||
1830mm | 3 | |||||
2030mm | 4 | |||||
2230mm | 4 | |||||
2430mm | 4 |
Wire Dia. | Mesh Size | Panel Width | Panel Height | Fold No. | Post’s height | Post Model | |
Fix Ⅰ | Fix Ⅱ | ||||||
3.5mm 4.0mm 4.5mm 5.0mm |
100*50mm 100*55mm 120*55mm 150*55mm |
2.0m 2.255m 2.5m 3.0m |
800mm | 2 | 1200 | 900 | Round shape |
1000mm | 2 | 1400 | 1200 | ||||
1200mm | 2 | 1600 | 1400 | ||||
1500mm | 3 | 2000 | 1700 | ||||
1700mm | 3 | 2200 | 1900 | ||||
2000mm | 4 | 2500 | 2200 | ||||
4.0mm 4.5mm 5.0mm 5.5mm 6.0mm |
200*50mm 200*55mm 200*60mm 200*65mm |
2.0m 2.255m 2.5m 3.0m |
830mm | 2 | 1200 | 900 | Square shapeRectangle shape
peach shape I shape |
1.30mm | 2 | 1400 | 1200 | ||||
1230mm | 2 | 1600 | 1400 | ||||
1530mm | 3 | 2000 | 1700 | ||||
1730mm | 3 | 2200 | 1900 | ||||
1830mm | 4 | 2300 | 2000 | ||||
2030mm | 4 | 2500 | 2200 | ||||
2230mm | 4 | 2700 | 2400 | ||||
2530mm | 5 | 3000 | 2600 |
Production Description:
Production Line of Welded Wire Mesh Fence
Our Customer
